Ebyte E22-400T33S User Manual

Chengdu Ebyte Electronic Technology Co., Ltd. E22-400T33S User Manual
Copyright ©2012–2022，Chengdu Ebyte Electronic Technology Co.,Ltd.
12
6.3 WOR transmitting mode（Mode 1）
Type
M0 = 1
，
M1 =0
Transmitting
Wireless data transmitting is enabled
Receiving
Wireless data receiving is enabled
6.4 Configuration mode（Mode 2）
Type
M0 = 0，M1 = 1
Transmitting
Wireless transmitting off
Receiving
Wireless receiving off
Configuration
Users can access the registers through the serial port to control the working status of the module
6.5 Deep sleep mode（Mode 3）
Type
M0 = 1
，
M1 = 1
Transmitting
Unable to transmit wireless data
Receiving
Unable to receive wireless data
Note
When entering other modes from sleep mode, the module will reconfigure parameters. During the configuration process, AUX
remains low; After completion, it outputs a high level, so it is recommended that the user detect the rising edge of AUX.
7 Register read and write control
7.1 Command format
In configuration mode (mode 2: M1 = 1, M0 = 0), the list of supported commands are as follows (only 9600, 8N1 format is
supported when)：
