Ebyte E840-DTU User Manual

Chengdu Ebyte Electronic Technology Co.,Ltd E840-DTU(4G-02E) User Manual
Copyright ©2012–2019
，
Chengdu Ebyte Electronic Technology Co.,Ltd
5
Class 2 (24dBm+1/-3dB) for TD-SCDMA bands
Class 3 (23dBm±2dB) for LTE-FDD bands
Class 3 (23dBm±2dB) for LTE-TDD bands
FDD B1: -101.5dBm (10M)
FDD B3: -101.5dBm (10M)
FDD B7: -99.5dBm (10M)
FDD B8: -101dBm (10M)
FDD B20: -102.5dBm (10M)
FDD B28A: -102dBm (10M)
WCDMA B1: -110dBm
WCDMA B8: -110.5Bm
GSM 3: -109dBm
GSM 8: -109dBm
Consumption
（Typical）
11uA @ power off
1.8mA @LTE sleep (PF=128)
1.5mA @LTE sleep (PF=256)
20mA @idle
Bandwidth
1.4/3/5/10/15/20MHz
Operating
temperature
-30℃- +70℃ extending to -40℃~+85℃
Operating voltage
DC ８V~２８V
Size
82×84×24mm
RS485 /RS232
RS485/RS232
