ECA CONFEO PREMIX P Series User Manual

15
1-

El
- lane Scres
2- Exhauste Gas Tap
- lane Gasets
3- ir Inlet Tap
- lue Exhaust Terminal
4- Sealin Gaset ∅ r ∅
- Inner Wall nnecn lane
5- Sealin Gaset ∅1 r ∅125
1- uter Wall nnecn lane ED
Table 3
7- FLUES
7.1- Flue Sizes
Flue gas connections between the boiler and the flue terminal must be made using original components
specially designed for the condensing boiler to ensure that the device operates efficiently and correctly.
Flue gas pipes and fittings of non-condensing boilers can not be used for exhausting gases from
condensing boilers. In the horizontal concentric flues, the exhaust gas pipe (the inner pipe) facing
outwards should be inclined upward and the fresh air pipe (outer pipe) should be inclined downward.
When the original flue set is installed parallel to the ground, the exhaust gas pipe is automatically
inclined upwards.
Equivalent length for each 90° elbow: 1 m
Equivalent length for each 45° elbow: 0.5 m
7.2- Flue Types
The terminals for the supply of combustion air and for the evacuation of combustion products shall not
be installed on opposite walls of the building. Information for C43 flue type is given below.
Cnfe Premix P
14 kW
20 kW
24 kW
28 kW
30 kW
35 kW
Flue gas max w
rate (gr/sec)
5,8996
8,428
10,1136
11,7208
13,6808
13,9552
Flue gas min w
rate (gr/sec)
2,2638
3,234
3,8808
2,744
3,528
3,6064
Flue gas max
temperature (C)
80
80
80
80
80
80
Flue gas min
temperature (C)
30
30
30
30
30
30
Flue gas Pressure
100 Pa
Table 4

ECA CONFEO PREMIX P Series Specifications

General

Brand	ECA
Model	CONFEO PREMIX P Series
Category	Boiler
Language	English
