ECD MiniM.O.L.E. - Power Source; Specifications

P/N A51-4473-16 Page 22 Rev 4.3.3
Power Source
The MiniM.O.L.E.® rH is powered by a 3.6 volt ½ AA lithium battery. If the LCD display is dim or does
not illuminate, check the battery to see if it has become discharged. Always replace with SAFT lithium
battery (LS 1425) or the equivalent specified.
Specifications
Electrical/Mechanical Spec:
PHYSICAL DIMENSIONS:
0.37 in. x 3.5 in. x 6 in. (9.41 mm x 89 mm x 152.4 mm)
TEMPERATURE MEASUREMENT RANGE:
-40 to 70°C (-40 to 158°F)
RH RANGE:
0 to 100% RH
*WARNING: Exceeding this temperature may permanently damage the equipment!
ACCURACY:
± 0.35°C (from -40°C to 0°C) or ±0.63°F (from -40°F to
+32°F)
±0.25°C (from 0° to +70°C) or ±0.45° (from +32°F to
+158°F)
Humidity ±3%
Resolution: 0.1
PROGRAMMABLE SAMPLING PERIOD:
1 second to 10 days
NUMBER OF SAMPLES PER CHANNEL:
32,000 (16,000 per sensor)
POWER SUPPLY:
3.6V ½ AA Lithium battery
