Hold, Serial, Password
Output → Hold
Sets the Hold “Time
Out” Function
Serial Configuratio
n
Address
(MODBUS + HART®)
Baud
(MODBUS only)
Format
(MODBUS only)
Format
(MODBUS only)
Password Protection
Choose Level
Enter 4 character
password, case
sensitive
Master Password in
Manual
16
