Wiring and Power Board
Color Code and
Connection type
embossed into the
protective Circuit
Board cover
110/220 VAC
110/220 VAC
Power Board
AC In 24 VDC Out
Optional preamp
for mV+, mV-, TC,
TC, SG input
