64
Appendix E:
Specifications
Audio Performance
Analog in to analog out
Frequency Response: 10Hz – 22kHz,
±
0.5dB
Dynamic Range: 98dB
THD+n: <0.005%, 20Hz–22kHz, A-weighted
Hardware
Eight ¼
"
TRS balanced analog inputs with precision 20-bit 128x
oversampling analog-to-digital converters
Ten ¼
"
TRS balanced analog outputs with high-performance 20-bit 128x
oversampling digital-to-analog converters
Outputs individually switchable between +4dBu and –10dBV
S/PDIF digital I/O with up to 24-bit resolution
On-board 24-bit Motorola 56301 DSP (80 MIPS)
24-bit data resolution maintained throughout internal signal path
Word clock/superclock I/O
Support for continuous sample rates with single-Hertz resolution
