Echo CS-310ES Service Data

SERVICE INFORMATION
CS-310ES
6
1.35
0.4
1.65
1.5
Ignition Air Gap Gauge
#.014 = .35mm
P/N 91004
0
0.4
50
0.8
1.2
1.
MPa
0
b
1207D
91019
1-6 Special tools
1
34
2
5
8
910 1211
13
7
6
1514 16
Key Part Number Description Reference
1 897801-33330 Tachometer PET-1000 Measuring engine speed
2 X605-000050 Torx L wrench Removing and installing bolt
3 897501-03938 Puller Removing magneto rotor
4 897505-16133 Clutch tool Removing and assembling clutch assembly
5 91037 Compression gauge Measuring cylinder compression
6 897702-30131 Piston pin tool Removing and installing piston pin
7 897701-06030 Bearing wedge Removing and crankshaft ball bearings
8 897563-19830 Metering lever gauge Measuring metering lever height on carburettor
9 X686-000000 ThreeBond 1207D Applying crankcase seam
10 91019 Limiter cap tool Removing and installing limiter cap
11 897726-21430 Oil seal tool Installing oil seals and clutch plate
12 897800-79931 Spark tester Checking ignition system
13 897803-30133 Pressure tester Testing carburettor and crankcase leakage
14 500-500 Welch plug tool Removing and installing welch plug tool
15 X646-000030 Auto-oiler tool Installing pencil type Auto-oiler
16 91004 Module air gap gauge Adjusting pole shoe air gaps
