Keep in mind that the wood is heavy and that it will bend and pinch the saw
if improperly supported. The trunk will weaken at the point where you make
the cut unless the tree is lying on perfectly flat ground or supported as
shown. If you make the cut with the tree on the ground, don’t let the saw’s
chain dig into the earth; it is harmful for the saw, and you stand a good
chance of being struck by flying debris.
To cut the trunk, use the bucking and two-cut sequence shown. The first cut
should be no deeper than one-third the trunk diameter.
Guide Bar and Chain Combination
The following combinations are recommended for model CS-3410.
Use of replacement saw chain and/or guide bar other than that
specified, or operation without the optional Kick Guard
TM
in
place, may cause severe kickback resulting in serious injury.
Chain and guide bar gauge size must be identical. Use bar/chain
combinations shown in the table above.
Kick Guard
TM
(Optional)
To purchase an optional Kick Guard
TM
contact your dealer. For the name of
the ECHO dealer nearest you, call 1-800-432-ECHO (3246) or on the web
at www.echo-usa.com. For the name of the Shindaiwa dealer nearest you,
call 1-877-986-7783 or on the web at www.shindaiwa-usa.com.
Guide Bar Saw Chain
Length mm (in.)
ECHO Part No.
Pitch (in.) Type Links
Low-kickback
356 (14) 14A0CD3752
3/8
91PX52CQ 52
406 (16) 16A0CD3757 91PX57CQ 57
