CS-3410 SAFETY
X7503361801 7
© 10/23 ECHO Incorporated
Note: Not all symbols will appear on your unit.
Chain Brake
Operation
Chain Oiler
Adjustment
Choke Control
“COLD START”
Position (Choke
Closed)
Choke Control
“RUN” Position
(Choke Open)
Purge Bulb
Decompression
Device
STOP /
Momentary
STOP Switch
Symbol Description Symbol Description
STOP
STOP
