Echo CS-355T-14 Service Manual

4
SERVICE INFORMATION
CS-355T
1-3 Torque limits
Descriptions
Size
kgf•cm
N•m
in•lbf
Starter
system
Starter pawl
M 5*
30 - 45
3 - 4.5
26 - 40
Starter case
M 4
15 - 20
1.5 - 2
13 - 17
Ignition
system
Magneto rotor (Flywheel)
M 8
250 - 290
25 - 29
220 - 255
Ignition coil
M 5*
30 - 45
3 - 4.5
26 - 40
Spark plug
M 14
130 - 170
13 - 17
110 - 150
Fuel
system
Carburetor
M 5
20 - 30
2 - 3
17 - 26
Intake bellows
M 5
30 - 50
3 - 5
26 - 45
Clutch Clutch hub
LM 10
230 - 260
23 - 26
200 - 230
Engine
Crankcase
M 5*
60 - 80
6 - 8
50 - 70
Engine mount
M 5
70 - 110
7 - 11
60 - 95
Muffler
M 5
70 - 100
7 - 10
60 - 90
Muffler cover
M 5
30 - 50
3 - 5
26 - 45
Others
Auto-oiler
M 4
20 - 30
2 - 3
17 - 26
Front handle
M 4*
15 - 30
1.5 - 3
13 - 26
Rear handle assembly
M 5
15 - 30
1.5 - 3
13 - 26
Harness fixture
M 5
60 - 90
6 - 9
50 - 80
Cap cover
M 5
30 - 45
3 - 4.5
26 - 40
Sprocket guard
M 4
15 - 25
1.5 - 2.5
13 - 22
Brake lever
M 5
25 - 40
2.5 - 4
22 - 35
Spike
M 5
30 - 50
3 - 5
26 - 45
Guide bar
M 8
200 - 230
20 - 23
175 - 200
Regular bolt, nut and screw
M 3
6 - 10
0.6 - 1
5 - 9
M 4
15 - 25
1.5 - 2.5
13 - 22
M 5
25 - 45
2.5 - 4.5
22 - 40
M 6
45 - 75
4.5 - 7.5
40 - 65
LM: Left-hand thread *Apply special repairing materials
1-4 Special repairing materials
Material
Location
Remarks
Adhesive
Ball bearing outer / crankcase
Loctite #675 or equivalent
Stud bolt
Liquid gasket
Crankcase seams
ThreeBond 1207D
Thread locking sealant
Starter pawl
Loctite #222, ThreeBond #1342 or equivalent
Ignition coil
Grease
Clutch needle bearing
Lithium based grease or ECHO XTended
Protection
TM
Lubricant
Starter center shaft
Chain brake (metal contact part)
Molybdenum grease (approx.1 gram)
