Echo CS-360T Service Data

2
SERVICE INFORMATION
CS-360T
CS-330T
1 SERVICE INFORMATION
1-1 Specifications
Model CS-330T CS-360T
Dimensions Length* mm(in) 277 (10.9)
Width mm(in) 247 (9.7)
Height mm(in) 214 (8.4)
Dry weight* kg(lb) 3.6 (7.9)
Engine Type KIORITZ, air-cooled, two-stroke, single cylinder
Rotation
Clockwise as viewed from the output end
Displacement cm
3
(in
3
) 32.6 (1.989) 36.3(2.215)
Bore
mm(in) 36.0 (1.417) 38.0 (1.496)
Stroke
mm(in) 32.0 (1.260) 32.0 (1.260)
Compression ratio 7.5
Carburetor Type Diaphragm horizontal-draft with auto-return choke
Model Walbro WT-739 Walbro WT-728
Venturi size-Throttle bore mm(in) 11.11 - 15.85 (0.437 - 0.624)
Ignition Type CDI (Capacitor discharge ignition) system
with electronic timing advancer and speed governor
Spark plug BPM8Y
Starter Type Automatic rewind
Rope diameter x length mm(in) 3.0 x 920 (0.12 x 36.2)
Fuel Type Premixed two-stroke fuel
Mixture ratio 50 : 1 (2 %)
Gasoline Minimum 89 octane gasoline
Two-stroke air cooled engine oi
l ISO-L-EGD (ISO/CD13738), JASO FC
Tank capacity L (U.S.fl.oz.) 0.31 (10.5)
Clutch Type Centrifugal, 3-shoe slide with 3-tension spring
Guide bar / Saw chain lubrication type Automatic with volume adjuster
Oil
Tank capacity
L (U.S.fl.oz.)
0.29 (9.8)
Sprocket
Type
Spur
Number of teeth
6
Pitch
in
3/8
* Without guide bar and saw chain.
Cutting devices
Guid
e bar
Par
t No. 120374501 140375201 160375701
Calle
d length in 12 14 16
Gauge in 0.050
Sa
w chain
T
ype OREGON 91VG
Numbe
r of drive links 45 52 57
Pitch in Low profile 3/8
Gauge in 0.050

Echo CS-360T Specifications

General

Brand	Echo
Model	CS-360T
Category	Chainsaw
Language	English
