GENERAL SAFETY PRECAUTIONS
English – 15
General advice on adjusting depth gauge setting
• When you sharpen the cutting tooth (A) the depth
gauge setting (C) will decrease. To maintain optimal
cutting performance the depth gauge (B) has to be
filed down to achieve the recommended depth gauge
setting. See instructions under the heading Technical
data to find the correct depth gauge setting for your
particular chain.
Adjustment of depth gauge setting
• The cutting teeth should be newly sharpened before
adjusting the depth gauge setting. We recommend
that you adjust the depth gauge setting every third
time you sharpen the cutting teeth. NOTE! This
recommendation assumes that the length of the
cutting teeth is not reduced excessively.
• You will need a flat file and a depth gauge tool. We
recommend that you use our depth gauge tool to
acheive the correct depth gauge setting and bevel for
the depth gauge.
• Place the depth gauge tool over the chain. Detailed
information regarding the use of the depth gauge tool,
will be found on the package for the depth gauge tool.
Use the flat file to file off the tip of the depth gauge that
protrudes through the depth gauge tool. The depth
gauge setting is correct when you no longer feel
resistance as you draw the file along the depth gauge
tool.
Tensioning the chain
The more you use a chain the longer it becomes. It is
therefore important to adjust the chain regularly to take up
the slack.
Check the chain tension every time you refuel. NOTE! A
new chain has a running-in period during which you
should check the tension more frequently.
Tension the chain as tightly as possible, but not so tight
that you cannot pull it round freely by hand. (11)
• Switch the engine off. (29)
• Release the knob by folding it out. (12)
• Turn the knob anti clockwise to loosen the bar cover.
(13)
• Adjust the tension on the chain by turning the chain
tensioner wheel down (+) for tighter tension and up (-
) to loosen the tension. Lift tip of guide bar while
adjusting tension. (14)
• Tighten the clutch cover by turning the knob clockwise
while lifting tip of bar. (15)
• Fold the knob back in to lock the tensioning. (16)
Lubricating cutting equipment
Chain oil
Chain oil must demonstrate good adhesion to the chain
and also maintain its flow characteristics regardless of
whether it is warm summer or cold winter weather.
As a chain saw manufacturer we have developed an
optimal chain oil which, with its vegetable oil base, is also
biodegradable. We recommend the use of Universal
Outdoor Accessories Chain Oil (Bio) for both maximum
chain life and to minimise enviromental damage. If
Universal Outdoor Accessories Chain Oil (Bio) is not
available, standard chain oil is recommended.
Never use waste oil! Using waste oil can be dangerous
to you and damage the machine and environment.
Filling with chain oil
• All our chain saws have an automatic chain lubrication
system. On some models the oil flow is also
adjustable.
• The saw chain oil tank and the fuel tank are designed
so that the fuel runs out before the saw chain oil.
However, this safety feature requires that you use the
right sort of chain oil (if the oil is too thin it will run out
before the fuel), and that you adjust the carburetor as
recommended (a lean mixture may mean that the fuel
lasts longer than the oil) and that you also use the
recommended cutting equipment (a bar that is too
long will use more chain oil).
!
WARNING! The risk of kickback is
increased if the depth gauge setting is
too large!
!
WARNING! A slack chain may jump off
the bar and cause serious or even fatal
injury.
!
WARNING! Always wear approved
protective gloves. Even a non-moving
chain can cause serious cuts to yourself
or persons you bump into with an
exposed chain.
