English – 31
TECHNICAL DATA
Recommended cutting equipment for USA
Following is a list of recommended cutting equipment for McCulloch chain saw models CS 410 Elite and CS 450 Elite.
These chain saw models equipped with either of the listed guide bar and saw chain combination(s), fulfills the
requirements according to ANSI B175.1-2000 (Gasoline Powered Chain Saws - Safety Requirements).
The following list is the chain saw manufacturers recommendations. There may be other combinations available, which
will also achieve kickback reduction.
Chain saw models McCulloch CS 410 Elite and CS 450 Elite met the kickback performance requirements of ANSI
B175.1-2000 when tested with the combinations of bars and saw chains listed below. The saw chain McCulloch H30 is
also classified as a low kickback saw chain since it met the requirements for low kickback saw chain outlined in ANSI
B175.1-2000. We recommend to use only the listed combinations of guide bars and saw chains for chain saw models
McCulloch CS 410 Elite and CS 450 Elite. Other chain saw models may not meet the kickback requirements when
equipped with the listed guide bar and saw chain combinations.
Recommended cutting equipment for Canada
Following is a list of recommended cutting equipment for the McCulloch chain saw models CS 410 Elite and CS 450
Elite. The listed combination(s) of powerhead, bar and saw chain meet all requirements outlined in Canadian Standards
Assosiation Z62.1-03 (Chain Saws) and Z62.3-04 (Chain Saw Kickback).
Furthermore the saw chain McCulloch H30 is evaluated and listed as a Type C Low Kickback Saw Chain according to
the provisions in Z62.3-04.
Kickback information
The guide bar nose radius is determined by either the maximum number of teeth in the nose sprocket or the
corresponding maximum nose radius of a solid bar.
As we are listing the maximum guide bar nose radius, you may use a guide bar with smaller nose radius than in our list.
For guide bars of the same length, all sprocket-nose guide bars of the same pitch and having the same number of
sprocket teeth may be considered to have equivalent kickback energy. A hard nose bar having the same length and nose
radius as a sprocket-nose bar may be considered to have equivalent or less kickback energy than the sprocket-nose bar.
Guide bar and saw chain combinations
The following cutting attachments are approved for the models McCulloch CS 410 Elite and CS 450 Elite.
Saw chain filing and file gauges
Guide bar Saw chain
Length, inch Pitch, inch Gauge, inch Max. nose radius Type Drive link count
13
0.325 0.050 10T McCulloch H30
56
15 64
16 66
18 72
