SAFETY CS-501P
18 X7503312804
© 01/20 ECHO Incorporated
Chain Brake
Operation
Chain Oiler
Adjustment
Choke Control
“COLD START”
Position (Choke
Closed)
Purge Pump
Measured
maximum
kickback value,
without brake, for
approved bar and
chain
combinations.
Symbol Description Symbol Description
