Echo CS-5100

SERVICE INFORMATION
CS-4400
CS-5100
5
1-4 Special repairing materials
Material Location Remarks
Adhesive Ball bearing outer / crankcase Loctite #675 or equivalent
Stud bolt Loctite #609, ThreeBond #1373 or equivalent
Engine cover, cushion Loctite #406 (424) or equivalent
Liquid gasket Crankcase seams Loctite #515 (990610-00051) or equivalent
Oil tank seams Loctite superflex #595, ThreeBond #1212 or
equivalent
Thread locking sealant Starter pawl screws Loctite #242, ThreeBond #1324 or equivalent
Cushion screws (Rear handle)
Engine mount bolts
Loctite #222, ThreeBond #1342 or equivalent
Brake weight nut
Crankcase
Grease Auto-oiler worm
Clutch needle bearing
Cushion, inside
Lithium based grease
Rewind spring
Oil seal lip
Cleaner lid
Chain brake (metal contact part) Molybdenum grease (approx. 1 gram)
