CS-590 SAFETY
X7503264706 23
© 09/2020 ECHO Incorporated
Note: Not all symbols will appear on your unit.
Chain Brake Operation
Chain Oiler
Adjustment
Choke Control “COLD
START” Position
(Choke Closed)
Choke Control “RUN”
Position (Choke Open)
Purge Pump
De-Compression
Device
STOP / Momentary
STOP Switch
Symbol Description Symbol Description
STOP
STOP
