MAINTENANCE CS-590
58 X7503264706
© 09/2020 ECHO Incorporated
• When chain has been filed on the
bar, supply sufficient oil to it, move
the chain slowly to wash away the
filings before using again.
• If the chain saw is operated with
filings clogged in the groove, the
saw chain and the guide bar will be
damaged prematurely.
• If the saw chain becomes soiled
with resin, for instance, clean it with
kerosene and soak in it oil.
To sharpen other chains, follow chain manufacturer’s instructions.
0.64 mm (0.025 in.)
Parallel
Depth gauge

Echo CS-590 Specifications

General

Engine Displacement	59.8 cc
Engine Type	2-stroke
Bar Length	20 inches
Power Output	4.0 HP
Weight	13.2 lbs
Chain Gauge	0.050 inches
Fuel Capacity	21.8 fl. oz (647 ml)
