EA-410 SPECIFICATIONS
© 10/2013 ECHO Inc.
X7504220703 29
SPECIFICATIONS
MODEL EA-410
Length 585 mm (23.0 in.)
Width 270 mm (10.6 in.)
Height 370 mm (14.6 in.)
Weight 9.8 kg (21.6 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 40.0 mm (1.58 in.)
Stroke 34.0 mm (1.34 in.)
Displacement 42.7 cc (2.61 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-7A (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X
TM
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD, two-stroke,
air-cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl
alcohol or 15% MTBE. Do not use alternative fuels such as E-15 or E-85.
Oil Power Blend X
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity 1.0 lit. (33.8 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Vibration Isolated System Cushioned left and right hand grips
PTO Shaft 22 mm (.875 in.) Diameter
Gear Case Ratio 30.2:1 Reduction
Auger Capacity 51 mm - 254 mm (2 in. - 10 in.)
Rotation Clockwise, viewed from top
Handle Cushioned Bow w/Grip
Idle Speed 2,500 RPM
Clutch Engagement Speed 3,600 RPM
Wide Open Throttle Speed (W.O.T.) 10,600 RPM
