10
Tools Required: Screwdriver.
Parts Required: Barrier Bar
Handle Adjustment
NOTE
Label shows minimum spacing for front handle location.
1. Stand in a comfortable operating position with attachment as-
sembled, and position front handle for comfortable operation.
Tighten handle screws.
Barrier Bar Assembly
NOTE
The barrier bar may be used with all attachments unless instructed
otherwise in the attachment Operator's Manual.
1. Unscrew bottom bracket of handle, and replace with Barrier Bar as
shown. Adjust handle and secure as described above.
FRONT HANDLE ADJUSTMENT/BARRIER BAR ASSEMBLY
MIN
SPACING
