Echo PB-2520 User Manual

ASSEMBLY PB-2520
16 X7501190003
©10/2019 ECHO Inc.
ASSEMBLY
Never perform maintenance or assembly procedures with
engine running or serious personal injury may result.
Install Blower Pipes
1. Stand unit upright on blower base.
2. Align large locking ribs (A) on
curved blower pipe with pipe
lock (B) in fan case. Slide
curved blower pipe into fan
case until a clicking sound is
heard.
Do not assemble the opposite
end of the curved blower pipe to
the fan case.
A
B

Echo PB-2520 Specifications

General

Engine Displacement	25.4 cc
Air Volume	453 CFM
Air Speed	170 MPH
Weight	8.6 lbs
Type	Handheld
Engine Type	2-stroke
Noise Level	70 dB(A)
Power Source	Gas
Fuel Capacity	16.9 fl. oz
