PB-2520 OPERATION
X7501190003 23
©10/2019 ECHO Inc.
Note: If engine does not start with choke in RUN position after 5
pulls, repeat instructions 3 - 6.
7. Throttle Trigger
After engine warm up, gradually depress throttle trigger to increase
engine RPM to operating speed.
Note: Allow engine to warm up 3 minutes before use.
Starting Warm Engine
The starting procedure is the same as Cold Start except DO NOT close the
choke.
1. Stop Switch
Move stop switch (A) away from
the STOP position.
2. Throttle Position Lever
Move throttle position lever (B)
midway between idle and full
throttle positions.
3. Purge Bulb
Pump purge bulb (D) until fuel is
visible and flows freely in the
clear fuel tank return line.
4. Recoil Starter
Place the unit on a flat, clear
area. Firmly grasp throttle
handle (E) with left hand and
rapidly pull recoil starter handle/
rope (F) until engine fires.
To Next Page
