Echo PB-580H User Manual

PB-580H/T OPERATION
X7505200705 25
© 12/2017 ECHO Inc.
ENGLISH
1. Remove back cushion (A) from
frame.
2. Install intake cover (B) on frame
over air intake.
3. Install back cushion (A) to
frame over intake cover.
Note: Blower performance may
be reduced slightly.
Adjust the Harness
1. Loosen upper and lower
buckles (A), then put blower on
your back.
2. Pull strap (B) downward to
adjust position of blower.
3. Pull (C) to adjust angle
between your back and the
blower.
A
B
A
A
A
A
C

Echo PB-580H Specifications

General

Engine Displacement	58.2 cc
Air Speed	215 mph
Type	Backpack Blower
Engine Type	2-stroke
Air Speed (m/s)	96 m/s
Weight	9.5 kg
Fuel Tank Capacity	1.1 L
Dry Weight	9.5 kg
