POWER BLOWER
OPERATOR'S MANUAL
SPECIFICATIONS
MODEL --------------------------------------------------------- PB-610
Length ------------------------------------------------------------ 325 mm (12.8 in.)
Width ------------------------------------------------------------- 520 mm (20.5 in.)
Height ------------------------------------------------------------ 435 mm (17.1 in.)
Weight (dry) ----------------------------------------------------- 10.9 kg (24.1 lb.)
Engine Type ----------------------------------------------------- Air cooled, two-stroke, single cylinder gasoline engine
Displacement ---------------------------------------------------- 58.2 mm (3.56 in.)
Bore --------------------------------------------------------------- 46.0 cc (1.81cu. in.)
Stroke ------------------------------------------------------------- 35.0 mm (1.38 in.)
Carburetor ------------------------------------------------------- Zama Diaphragm model w/purge bulb
Ignition System ------------------------------------------------- Flywheel Magneto, capacitor discharge ignition type
Spark Plug ------------------------------------------------------- NGK BPM-8Y Gap 0.65 mm (0.026 in.)
Exhaust System ------------------------------------------------- Spark arrestor - catalytic muffler / muffler
Fuel --------------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ---------------------------------------------------- 50:1 two-stroke air cooled engine oil
Gasoline ---------------------------------------------------------- Use 89 Octane [R+M/2] (mid grade or higher) gasoline known
to be good quality. Gasoline may contain up to 10% Ethanol
(grain alcohol) or 15% MTBE (methyl tertiary-butyl ether).
Gasoline containing methanol (wood alcohol) is NOT ap-
proved.
Oil ---------------------------------------------------------------- Power BlendX
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity --------------------------------------------- 1.9 lit. (64.3 US fl. oz.)
Recoil Starter System ------------------------------------------- Automatic Recoil Starter Centrifugal Type
Idle Speed -------------------------------------------------------- 2,400 - 3,000 (RPM)
Wide Open Throttle Speed ------------------------------------ 7,300 - 7,600 (RPM)
Maximum Air Speed (Measured at pipe end) --------------- 297.7 KM/H (185 mph)
Average Air Volume (Measured at pipe end) --------------- 15.0 m
3/
min. (530 cu. ft./min.)
Sound Level at 50 ft. dB(A) scale per ANSI B175.2 ------ 72 dB(A)
