8
1. AIR CLEANER - Contains replaceable air filter element.
2. SPARK PLUG - Provides spark to ignite fuel mixture.
3. SAFETY DECAL - Lists important safety precautions.
4. SPARK ARRESTOR - CATALYTIC MUFFLER / MUFFLER - The muffler or catalytic muffler controls exhaust
noise and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler.
Keep exhaust area clear of flammable debris.
5. CHOKE - Move lever up to "Cold Start" ( ) starting position and for emergency stopping. Move lever down to
Run position ( ).
6. PRIMER BULB - Pumping primer bulb before starting engine draws fresh fuel from the fuel tank, priming the
carburetor for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump
bulb an additional 4 or 5 times.
7. RECOIL STARTER HANDLE - Pull recoil handle slowly until starter engages, then quickly and firmly. When
engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
8. FUEL TANK - Contains fuel and fuel filter.
9. FUEL TANK CAP - Covers and seals fuel tank.
10. HANDLE - Rotates downward for throttle control access. Spring loaded for flexible operation.
11. BLOWER PIPES - Exclusive positive locking system.
12. SHOULDER HARNESS - Used to support unit on operator's back. The straps are adjustable.
13. THROTTLE POSITION LEVER/STOP SWITCH - Combination stop switch and variable speed throttle lever.
When the lever is moved all the way forward the blower is at Wide Open Throttle (W.O.T.). When the lever is
moved rearward to detent, the blower is at idle. When the lever is moved rearward past the idle detent the blower will
stop.
14. STICK HANDLE - Provides comfortable grip for directing air flow.
