REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR -- WYJ-250B1A021000052
SCREW2123114406301
BRACKET, CABLE1P0030001802
THROTTLE VALVE ASY
1
1------------------3
SCREW, IDLE ADJUST1123134400304
SWIVEL1123172451305
WASHER1123149542306
RING, RETAINING1123173079307
BODY, CARBURETOR
1
1------------------8
O-RING1123183059609
JET1P00300026010
INCLUDES ITEMS 12-17BASE, PURGE11231790556011
STRAINER1------------------12
SCREW, METERING LEVER PIN11231390556013
VALVE, INLET NEEDLE1------------------14
SPRING, METERING LEVER11231220556015
PIN, METERING LEVER11231380393016
LEVER, METERING1------------------17
BASE, PURGE11231800556018
BULB, PURGE11231814063019
RETAINER, PURGE BULB11231420556020
SCREW, PUMP COVER41231100556021
INCLUDES ITEMS 23-30REPAIR KIT1P00300019022
PACKING, RING1------------------23
GASKET, PUMP1------------------24
DIAPHRAGM, PUMP1------------------25
STRAINER1------------------26
VALVE, INLET NEEDLE1------------------27
LEVER, METERING1------------------28
GASKET, DIAPHRAGM1------------------29
DIAPHRAGM, METERING1------------------30
INCLUDES ITEMS 32-36DIAPHRAGM/GASKET KIT1P00300020031
PACKING, RING1------------------32
GASKET, PUMP1------------------33
DIAPHRAGM, PUMP1------------------34
GASKET, DIAPHRAGM1------------------35
DIAPHRAGM, METERING1------------------36
Footnotes
1: NOT AVAILABLE SEPARATELY
99922203284_260/04 - 15 - REVISED 02/03/11
