DESCRIPTION PPT-2620
18 X7507820600
© 2/2017 ECHO Inc.
16. FUEL TANK - Contains fuel and fuel filter.
17. FUEL TANK CAP - Covers and seals fuel tank opening.
18. PURGE BULB - Pumping purge bulb before starting engine draws
fresh fuel from the fuel tank, purging air from the carburetor.
Pump purge bulb until fuel is visible and flows freely in the clear
fuel tank return line. Pump purge bulb an additional 4 or 5 times.
19. AIR CLEANER ASSEMBLY - Contains replaceable air filter element.
20. CHOKE - The choke control is located at the rear of the air cleaner
housing. Move choke lever to COLD START ( ) to close choke for
cold start. Move choke lever to “RUN” ( ) position to open choke.
21. SPARK PLUG - Provides spark to ignite fuel mixture.
22. TOP GUARD - Provides arm rest during operation and protects arm
from hot engine.
23. GUIDE BAR COVER - Used to cover guide bar and saw chain during
transport and storage. Remove guide bar cover before using unit.
