Echo PWE-1800

• The adjustable spray nozzle had has two (2) positions (Fig. 10):
IN position for high pressure spray. Twist the nozzle counterclockwise until it stops and gap is closed.
OUT position for low pressure spray for detergent function. Twist the nozzle clockwise until it stops and
gap is open.
• When using the High Pressure setting twist the nozzle head clockwise or counterclockwise to achieve the
stream desired.
• When using the Low Pressure setting twist the nozzle head clockwise to open the fan blades all the way.
IMPORTANT NOTE: When applying detergent using low pressure spray, the variable spray head must be
set for the “Pencil Stream”. This is when the metal blades in front of the nozzle is wide open so the detergent
spray is not constricted.
• When using the detergent, ll it with a properly formulated detergent or cleaner with water ratio accord-
ing to instructions on the container (Fig. 11). The detergent tank comes with a straw which is tted into the
screw-on top. If you don’t see the straw, look inside the tank and attach it to the screw-on top (Fig. 12).
• When removing the detergent tank remove lid and place nger in tank lifting up while pulling tank out.
Fig.10
Fig.11 Fig.12
High pressure setting
IN position
IN position
Pencil Spray
Pencil Spray
Fan
Spray
OUT position
OUT position
High pressure
setting
Low pressure
setting
Low pressure setting
11
