18
When spraying is finished
∗ Drain cap
Fill chemical tank with water and spray through nozzle for 2 to 3 minutes for cleaning.
Drain water from the machine by removing drain cap.
Wipe off the liquid chemical on the machine after use.
∗ Grand nut
If chemical liquid leaks or discharge pressure goes down, turn grand nut as shown.
1. Grease cup
2. Oil gauge
To supply grease, turn grease cup clockwise one turn weekly.
When grease in grease cup becomes empty, remove the cup and refill grease.
To see oil level check oil gauge before operation by watching it from the side of the
machine.
If oil level is below half, add some more oil.
Use normal engine oil (SC, SD, SE SAE#30 or equivalent.)
