21
Specifications
∗ Technical data may be changed without advance notice.
∗ Other nozzles are available as optional supply.
∗ For some country, a optional nozzle is supplied as standard supply and two-head nozzle is available at extra cost.
Model
Mass: Without spraying hose and nozzle kg 9.0
Volume:
Chemical tank
Fuel tank
L
L
25
0.75
External dimensions: Length × Width × Height mm 340 × 450 × 620
Engine:
Type
Engine displacement
Engine speed
Carburettor
Magneto
Spark plug
Starter
mL (cm
3
)
r/min
Air cooled 2-stroke single cylinder
22.8
6000
Circulation type
Flywheel magneto, CDI system
NGK BPM7Y
Recoil starter
Fuel:
Oil
Mixture ratio
Regular grade petrol.
Minimum 89 Octane unleaded petrol is recommended.
Do not use fuel containing methyl alcohol or more than
10 % of ethyl alcohol.
Two stroke, air-cooled engine oil.
50 : 1 (2 %) for ISO-L-EGD Standard (ISO/CD13738),
JASO FC, FD grade and ECHO Premium 50 : 1 oil or
25 : 1 (4 %) for JASO FB grade oil.
Pump:
Type
Discharge volume
Pressure
L/min
MPa
Duble acting piston pump
5.8
2.5 Maximum (25 kgf/cm² Maximum)
Nozzle: Two-head nozzle
Spraying hose: ø8.5 mm × 1.1 m (Option : 1.5 m)
