8
DESCRIPTION
The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions,
shield installation and other assembly may be necessary.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing
parts. Use the contents list to check for missing parts.
CONTENTS
1 - Power Head
1 - Drive Shaft Assembly
1 - Plastic Bag (co-pack)
- 1, Operator's Manual
- 1, Safety Manual
- 1, Warranty Registration Card
- 1, Limited Warranty Statement
- 1, Plastic shield
- 1, Tool Bag
--1, T-wrench
--1, locking tool
- 1, Nylon Trimmer Head
- 1, Safety Glasses
- 1, 2-Stroke Oil Sample, 2.6 oz.
- 1, Front Handle (L.H.)
- 1, Plastic Bag
--1, shield plate
--3, 5mm x 15mm screws (shield mtg.)
3
4
5
6
7
8
9
10
11
1
2
12
14
15
16
17
18
19
20
13
21
