10 X7702093705
© 4/2015 ECHO Inc.
DESCRIPTION 99944200475
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow
the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See
PARTS ORDERING instructions for specific information.
1. BLADE - Rotates to provide cutting action.
2. DEBRIS SHIELD/FLAP - Mounted over the cutting attachment. Helps protect operator by deflecting
debris produced during the edging operation.
3. DRIVE SHAFT ASSEMBLY - Contains a specially designed liner and the flexible drive shaft.
4. WHEEL - Adjustable up/down, sets depth of blade.
