Echo SRM-225SB

REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEM 2-20SHORT BLOCK1SB10961
SCREW 5X222900162050222
CYLINDER1A1300005403
GASKET, CYLINDER
1
1V1000001604
INCLUDES ITEMS 6-9PISTON KIT1P0210077125
RING, PISTON1A1010000906
PIN, PISTON1100013115207
CIRCLIP, PISTON PIN2100015046308
SPACER, PISTON PIN2100014115209
INCLUDES ITEM 11CRANKSHAFT ASY1A01100010110
BEARING, NEEDLE1V55300006011
INCLUDES ITEMS 13-17CRANKCASE KIT11002045213212
OIL SEAL21002124203113
DOWEL PIN - 4X7.8mm2V62200002014
BEARING, BALL - 62012940353620115
GASKET, CRANKCASE
1
11002424203016
SCREW 5X2839001620502817
SHIELD, EXHAUST
1
1V10400085018
SHIELD, INTAKE
1
1V10300049019
GASKET, INTAKE
1
1V10300048020
Footnotes
1: Also Included In GASKET KIT
99922200782 - 19 - REVISED 04/22/09
Table of Contents Part Number Index
SRM-225SB Split Shaft Trimmer Engine, Short Block -- SB1096
