SRM-2400, SRM-2410 - TYPE 1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
36
36
37
38
39
40
41
42
43
44
45
46
SERIAL NUMBER: 001001 - 559293
35120152130 1 HANDLE ASY, LOOP INCLUDES ITEMS 2-6
35121351730 1 GRIP, FRONT HANDLE
35121051730 1 HANDLE, FRONT
90024605030 2 SCREW 5X30
90024205035 4 SCREW 5X35
90050000005 4 NUT 5
SERIAL NUMBER: 559294 - 566210
P021000000 1 HANDLE ASY INCLUDES ITEMS 8-13
35120507130 1 HANDLE, FRONT
90024205014 2 SCREW 5X14
90024205035 4 SCREW 5X35
35123207131 1 BRACKET, HANDLE
35122507130 1 BRACKET, HANDLE
90050000005 4 NUT 5
SERIAL NUMBER: 566211 & UP
P021000020 1 HANDLE ASY INCLUDES ITEMS 15-21
35121666230 1 GRIP, FRONT HANDLE
35120566230 1 HANDLE, FRONT
90060000005 2 WASHER
88995021060 2 SCREW
90024205035 4 SCREW 5X35
35122507130 1 BRACKET, HANDLE
90050000005 4 NUT 5
89022809560 1 LABEL, CAUTION - SPANISH
89016054130 1 LABEL, CAUTION
30120708930 1 HOOK INCLUDES ITEM 25
90010005018 1 BOLT 5X18
30120029430 1 BAND INCLUDES ITEM 27
90024205014 1 SCREW 5X14
16340049230 1 SWITCH, IGNITION
17800352130 1 THROTTLE BRACKET SET INCLUDES ITEMS 30-32
90050000005 2 NUT 5
90024205035 1 SCREW 5X35
90024205025 1 SCREW 5X25
17801052130 1 CONTROL, THROTTLE
17804342230 1 SPRING, THROTTLE RETURN
17812752130 1 TUBE
17800144430 1 CABLE, THROTTLE SERIAL NUMBER: 001001-509053
17800156730 1 CABLE, THROTTLE SERIAL NUMBER: 509054-562999
17800156530 1 CABLE, THROTTLE SERIAL NUMBER: 563000 & UP
90050200006 2 NUT 6 SERIAL NUMBER: 001001-562999
35121352130 1 GRIP, FRONT HANDLE
61027252130 1 BAND 25 INCLUDES ITEMS 40-41
90024205028 1 SCREW 5X28
90050000005 1 NUT 5
61060944730 1 DRIVE SHAFT HOUSING ASY INCLUDES ITEMS 43-44
61024644730 2 FIXTURE, LINER
61021744730 1 LINER, FLEXIBLE
61001344730 1 SHAFT, FLEXIBLE
89015204930 1 LABEL, CAUTION
SRM-2400 TYPE 1E
HANDLE, STOP SWITCH, THROTTLE CABLE, DRIVESHAFT
