Echo SRM-2400 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 User Manual

15
SRM-2400, SRM-2410 - TYPE 1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
20
21
22
23
24
25
SERIAL NUMBER: 503954 & UP
C400000000 1 HANDLE, FRONT
35131102330 1 GRIP, HANDLE
35130152130 1 HANDLE BRACKET ASY INCLUDES ITEMS 4-8
35142152130 1 BOLT
60501454230 1 WASHER
90016205020 2 BOLT 5X20
90016205030 3 BOLT 5X30
90056550008 1 NUT
35110247530 1 FRONT HANDLE GRIP ASY INCLUDES ITEMS 10-12
90024603025 4 SCREW 3X25
90022005030 1 SCREW 5X30
90050000005 1 NUT 5
16340048030 1 SWITCH, IGNITION
17801205960 1 LOCKOUT, THROTTLE
17801335631 1 SPRING, THROTTLE LOCK
17801005960 1 CONTROL, THROTTLE
15911209960 1 CLIP
V475000000 1 TUBE
17800147530 1 CABLE, THROTTLE SERIAL NUMBER: 001001-503484
17800156430 1 CABLE, THROTTLE SERIAL NUMBER: 503485 & UP
90050300006 2 NUT 6
30120021330 1 HOOK ASY INCLUDES ITEM 22
90010005012 1 BOLT 5X12
22492452130 2 CLIP
30100052131 1 HARNESS, SHOULDER
30110541830 1 CUSHION
DRIVE SHAFT, HANDLES, THROTTLE, STOP SWITCH, HARNESS
SRM-2410 TYPE 1E

Echo SRM-2400 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 Specifications

General

Brand	Echo
Model	SRM-2400 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001
Category	Trimmer
Language	English
