SRM-2400, SRM-2410 - TYPE 1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
61040240930 1 HOUSING ASY, GEAR INCLUDES ITEMS 2-23
90070600010 1 CIRCLIP 10
90070200022 1 CIRCLIP 22
90085806900 1 BEARING, BALL 6900
90085506900 1 BEARING, BALL 6900
61030044830 1 GEAR SET, BEVEL
90030020022 1 PIN, SPLIT 2X22
90051100010 1 NUT 10 - LEFT HANDED
61031404131 1 PLATE, ADAPTER - LOWER
61033808930 1 PLATE, ADAPTER - UPPER SRM-2410 WITH BLADE ONLY
61041307130 1 OILSEAL
90070200032 1 CIRCLIP 32
61031507130 1 SPACER
9403536201 1 BEARING, BALL 6201
61036008931 1 SHAFT, P.T.O.
90070600012 1 CIRCLIP 12
90080000609 1 BEARING, BALL 609
61023904130 2 WASHER, SHIM
61046027430 1 CASE, GEAR
90024205010 1 SCREW 5X10
90010008008 1 BOLT 8X6
90010005035 2 BOLT 5X35
90060000005 2 WASHER
69900023431 1 SHIELD ASY INCLUDES ITEMS 25-28
90060500005 4 WASHER, SPRING 5
90050000005 4 NUT 5
90022005008 2 SCREW 5X8
90024205010 3 SCREW 5X10
89011848830 1 LABEL, ECHO
89016841031 1 LABEL, CAUTION
89541008030 1 WRENCH, W/SCREWDRIVER
89511200330 1 SPANNER 8X10
89561203430 1 L-WRENCH - 3mm
BULK OPTION
89850201130 1 PIN 2X22, COTTER - 10 PINS PER PACKAGE
GEAR CASE, SHIELD, TOOLS
