Echo SRM-2400 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 User Manual

19
SRM-2400, SRM-2410 - TYPE 1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
SERIAL NUMBER: SRM-2400 -- 001001-515387, SRM-2410 -- 001001-505362
69900440931 1 SHIELD ASY INCLUDES ITEMS 2-6
69901027231 1 SHIELD, BLADE
90023805016 5 SCREW 5X16
69901644330 1 CUTTER
90050000005 2 NUT 5
69901840830 1 BRACKET, SHIELD
89016844830 1 LABEL, CAUTION
89011848830 1 LABEL, ECHO
SERIAL NUMBER: SRM-2400 -- 615388 & UP, SRM-2410 -- 505363 & UP
P021001391 1 SHIELD ASY INCLUDES ITEMS 10-12
90023805016 2 SCREW 5X16
69901644330 1 CUTTER
90050000005 2 NUT 5
69901840830 1 BRACKET, SHIELD
90023805016 3 SCREW 5X16
SHIELDS
