SRM-2400, SRM-2410 - TYPE 1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
ENGINE, CRANKCASE, CYLINDER COVER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
OPTIONAL ENGINE REPOWER
SB1027 1 SHORT BLOCK INCLUDES ITEMS 2-17
10100308960 1 CYLINDER W/ PISTON INCLUDES CYLINDER, PISTON, & ITEMS 6 & 8
90016205022 2 BOLT 5X22
10101044332 1 GASKET, CYLINDER
10000009563 1 PISTON KIT INCLUDES ITEMS 6-9
10001109560 2 RING, PISTON
10001311520 1 PIN, PISTON
10001504630 2 CIRCLIP, PISTON PIN
10001411520 2 SPACER, PISTON PIN
10001251230 1 BEARING, NEEDLE
A011000101 1 CRANKSHAFT ASY
10020451030 1 CRANKCASE KIT INCLUDES ITEMS 13-17
10021242030 2 SEAL, OIL
10021503930 2 PIN, DOWEL
9403536201 2 BEARING, BALL
10024242030 1 GASKET, CRANKCASE
90016205028 3 BOLT 5X28
90023805016 1 SCREW 5X16
15991254130 1 GUARD, TOP
10151448930 1 COVER, CYLINDER
90016304016 2 SCREW 4X16
GASKET KIT - SERIAL NUMBER: SRM-2400 -- 001001-562999 & SRM-2410 -- 001001-503485
88900005960 1 GASKET KIT
GASKET KIT - SERIAL NUMBER: SRM-2400 -- 563000 & UP & SRM-2410 -- 503486 & UP
88900004861 1 GASKET KIT
Also Included In GASKET KIT
