Echo SRM-2400 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 User Manual

5
SRM-2400, SRM-2410 - TYPE 1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
IGNITION, FAN CASE
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
22
21
22
90016204022 2 BOLT 4X22
16201052830 1 LEAD
15611240630 1 GROMMET
15901201620 1 CAP, SPARK PLUG
15901103432 1 TERMINAL, SPARK PLUG CAP
99944500071 1 PLUG, SPARK BPM-7Y
BPMR-7A 1 PLUG, SPARK CANADA MODELS
61090355230 1 HOLDER KIT INCLUDES ITEMS 8-10
90014205025 2 BOLT 5X25
61092227432 1 HOLDER
61092355230 1 HOLDER
17811106230 1 CLAMP SERIAL NUMBER: 503485 & UP
61091055230 1 CUSHION
89011252130 1 LABEL, MODEL -- SRM-2400
89013552130 1 LABEL, MODEL -- SRM-2410
10150352131 1 FAN COVER
90016304016 6 SCREW 4X16
90070100012 1 CIRCLIP 12
90080796001 2 BEARING, BALL
90070200028 1 CIRCLIP 28
17500548931 1 DRUM, CLUTCH
17500056830 1 CLUTCH ASY
SERIAL NUMBER: 001001-501000
15660152130 1 COIL, IGNITION
15680144731 1 FLYWHEEL
SERIAL NUMBER: 501001 & UP
15662652730 1 COIL, IGNITION
15680109660 1 FLYWHEEL
