SRM-2400, SRM-2410 - TYPE 1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
STARTER, FUEL SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
27
17720244330 1 STARTER PAWL ASY INCLUDES ITEMS 2-3
17723442030 1 SPRING, RETURN
17721844330 1 PAWL, STARTER
17720042033 1 STARTER ASY INCLUDES ITEMS 4-11
17723644330 1 SCREW
17721544430 1 DRUM, STARTER
17722610120 1 ROPE, STARTER 3mm(1/8") X 1000mm(39-1/2"), BULK OPTION: 99944444000
17722742030 1 GUIDE, ROPE
17722806530 1 GRIP, STARTER
17722042030 1 SPRING, REWIND
17723242032 1 CASE, STARTER
90016304016 4 BOLT 4X16
89011849130 1 LABEL, ECHO
13201013930 1 PIPE, FUEL - 3X5X180mm BULK OPTION: 90014
A356000030 1 VALVE, CHECK
13131239130 1 PIPE, VENT - 3X5X70mm BULK OPTION: 90014
13211546730 1 GROMMET, FUEL
13201309820 1 CLIP
13120507320 1 FILTER, FUEL
13100544331 1 TANK, FUEL INCLUDES ITEM 22
13104528230 2 COLLAR
90060300005 2 WASHER 5
90023805016 2 SCREW 5X16
13100455830 1 FUEL TANK CAP ASY INCLUDES ITEM 26
13101655830 1 GASKET, FUEL TANK CAP
30511042030 1 STAND
SERIAL NUMBER: SRM-2400 -- 001001-562999, SRM-2410 -- 001001-501557
13201056330 1 PIPE, RETURN - 3X6X90mm BULK OPTION: 90017
SERIAL NUMBER: SRM-2400 -- 563000 & UP, SRM-2410 -- 501558 & UP
13201256030 1 PIPE, RETURN - 3X6X80mm BULK OPTION: 90017
Part Number New To This Edition =
