Echo SRM-2400 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 User Manual

9
SRM-2400, SRM-2410 - TYPE 1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
INTAKE, EXHAUST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
32
33
34
35
36
37
38
39
40
41
42
43
14580052631 1 MUFFLER ASY INCLUDES ITEMS 2-8
V104000160 2 SHIELD, MUFFLER
14587152130 1 COVER, MUFFLER
14586240630 1 SCREEN, MUFFLER
14586642031 1 GASKET, MUFFLER LID
14587642030 1 LID, MUFFLER
14581852130 1 GUIDE, EXHAUST
90023804010 3 SCREW 4X10
90060000005 2 WASHER 5
90010505055 2 BOLT 5X55
SERIAL NUMBER: SRM-2400 -- 001001-562999, SRM-2410 -- 001001-503485
13030252130 1 AIR CLEANER COVER ASY INCLUDES ITEMS 12
13040652130 1 THUMB SCREW
89012152130 1 LABEL, CHOKE
13031051830 1 FILTER, AIR
90024205057 2 SCREW 5X57
12901152130 1 PLATE, PRE-VENT
90060000005 1 WASHER 5
17851505060 1 SHUTTER, CHOKE
17851600830 1 WASHER 5
13031451730 1 CASE, AIR CLEANER
17881005230 1 GROMMET, CHOKE
17851051730 1 KNOB, CHOKE
12300052131 1 CARBURETOR -- WT-424A
13001005960 1 GASKET, INTAKE
90023805020 2 SCREW 5X20
13001742031 1 INSULATOR
90050000005 2 NUT 5
13001042032 1 SHIELD, CYLINDER
88900005960 1 GASKET KIT
SERIAL NUMBER: SRM-2400 -- 563000 & UP, SRM-2410 -- 503486 & UP
13040652130 1 THUMB SCREW
13031357731 1 LID, CLEANER
89012152730 1 LABEL, CHOKE
89033252730 1 LABEL, CHOKE --CANADA MODELS
13031051830 1 FILTER, AIR
90024205065 2 SCREW 5X65
12901157730 1 PLATE, PRE-VENT
13030757730 1 CASE, CLEANER
12300051730 1 CARBURETOR -- WYJ-22
13001044431 1 GASKET, INTAKE
90023805020 2 SCREW 5X20
13001744330 1 INSULATOR
90050000005 2 NUT 5
13001042032 1 SHIELD, CYLINDER
88900004861 1 GASKET KIT
Also Included In GASKET KIT
