Echo SRM-2655SI - 1-3 Torque limits; 1-4 Special repairing materials

SERVICE INFORMATION SRM-2655SI
4
1-3 Torque limits
Descriptions Size kgf•cm N•m in•lbf
Starter Pawl carrier M 8 90 - 120 9 - 12 80 - 100
system
Starter case M 4* 14 - 28 1.4 - 2.8 12 - 24
Ignition Magneto rotor (Flywheel) M 8 160 - 200 16 - 20 140 - 175
system
Ignition coil M 5 40 - 60 4 - 6 35 - 52
Fan cover M 5 30 - 45 3.0 - 4.5 25 - 40
Spark plug M 14 150 - 170 15 - 17 130 - 150
Fuel Carburettor insulator M 5 50 - 70 5 - 7 45 - 60
system
Carburettor M 5 30 - 45 3.0 - 4.5 25 - 40
Fuel tank M 5 30 - 45 3.0 - 4.5 25 - 40
Stand Starter side M 5 20 - 30 2 - 3 17 - 26
Fan cover side M 5 30 - 45 3.0 - 4.5 25 - 40
Clutch Clutch shoe M 6 70 - 110 7 - 11 60 - 95
Engine Crankcase M 5 70 - 110 7 - 11 60 - 95
Cylinder M 5 70 - 110 7 - 11 60 - 95
Top guard M 5* 30 - 45 3.0 - 4.5 25 - 40
Muffler M 5 60 - 100 6 - 10 52 - 85
Muffler cover M 5* 14 - 28 1.4 - 2.8 12 - 24
Others Blade fastening nut LM 10 280 - 320 28 - 32 245 - 280
Regular bolt, nut, M 3 6 - 10 0.6 - 1.0 5 - 9
and screw M 4 15 - 25 1.5 - 2.5 13 - 22
M 5 25 - 45 2.5 - 4.5 22 - 40
M 6 45 - 75 4.5 - 7.5 40 - 65
M 8 110 - 150 11 - 15 95 - 130
M 10 210 - 300 21 - 30 180 - 260
LM: Left hand thread.
* Apply thread locking sealant. (See below)
1-4 Special repairing materials
Material Location Remarks
Thread locking sealant Muffler cover Loctite #242, ThreeBond 1324 or equivalent
Starter case
Loctite #222, ThreeBond 1342 or equivalent
Top guard
Grease Gear case
Rewind spring Lithium based grease
Starter drum center hole
