Echo SRM-3155(SI)

SRM-3155(SI),3605(SI)
5. Air Cleaner, Muffler
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
3 130016-55430 1 GASKET, INTAKE
4 900500-00005 2
NUT 5
5
5 900162-05025 2
BOLT, H.S. 5*25
5*25 W,SW
6 130017-55630 1
INSULATOR
7 130010-05960 1
GASKET, INTAKE
8 123000-55630 1
CARBURETOR WT-344
WT-344
9 178510-51730 1
ROD, CHOKE
10 130301-51730 1
CASE, AIR CLEANER
11 + 178810-05230 1
GROMMET
12 178516-00830 1
SPACER
5.2*8*0.8T
13 178515-05060 1
SHUTTER, CHOKE
14 129011-52130 1
PLATE
Sus. by 129011-
52131
14 129011-52131 1
PLATE
15 900162-05057 2
BOLT, H.S. 5*57
5*57 W,SW
16 130310-51730 1
FILTER, AIR
17 890121-47530 1
LABEL, CHOKE
18 130302-52130 1
COVER ASSY, AIR CLN.
Sus. by 130302-
52131
18 130302-52131 1
COVER ASY, A.CLEANER
20 + 130406-52130 1
KNOB, FASTENER
Sus. by 130406-
52131
20 + 130406-52131 1
KNOB, FASTENER
25 145510-55430 1
GASKET, MUFFLER
26 145610-55230 1
MUFFLER
27 900105-05060 2
BOLT, H.S. 5*60
5*60
- 10 -
