Echo SRM-400

REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR -- WYK-152C1A021000302
SCREW, CABLE BRACKET2123114406301
BRACKET, CABLE1P0030001802
THROTTLE VALVE ASY
1
1------------------3
SCREW, IDLE ADJUST1123134400304
SWIVEL1123172451305
WASHER1123149542306
CLIP, SWIVEL1123173079307
BODY, CARBURETOR
1
1------------------8
INCLUDES ITEM 10JET KIT1P0030006909
O-RING11231834063010
INCLUDES ITEMS 12-17PUMP BODY ASY1P00300051011
SCREEN, INLET1------------------12
VALVE, INLET NEEDLE1------------------13
SPRING, METERING LEVER1------------------14
LEVER, METERING1------------------15
PIN, METERING LEVER1------------------16
SCREW, METERING LEVER PIN11231390556017
BODY, AIR PURGE11231800556018
PUMP, PRIMER11231814063019
COVER, PRIMER PUMP11231420556020
SCREW, PUMP COVER41231100556021
INCLUDES ITEMS 23-32REPAIR KIT1P00300066022
RING, PACKING1------------------23
GASKET, PUMP1------------------24
DIAPHRAGM, PUMP1------------------25
SCREEN, INLET1------------------26
VALVE, INLET NEEDLE1------------------27
SPRING, METERING LEVER1------------------28
LEVER, METERING1------------------29
PIN, METERING LEVER1------------------30
GASKET, METERING DIAPHRAGM1------------------31
METERING, DIAPHRAGM1------------------32
INCLUDES ITEMS 34-38GASKET/DIAPHRAGM KIT1P00300065033
RING, PACKING1------------------34
GASKET, PUMP1------------------35
DIAPHRAGM, PUMP1------------------36
GASKET, METERING DIAPHRAGM1------------------37
METERING, DIAPHRAGM1------------------38
Footnotes
1: NOT AVAILABLE SEPARATELY
99922204184 - 11 - REVISED 10/01/07
Table of Contents Part Number Index
SRM-400 Brushcutter Carburetor -- WYK-152C
