Echo TRIMMER SRM-230 User Manual

REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR -- RB-K70A1A021000721
ROTOR COVER ASY1P0050016201
SCREW, ROTOR COVER ASY3125344139312
SCREW, ROTOR COVER1125344521303
SCREW, CABLE ADJUST1P0050013304
SWIVEL1P0050012405
E-RING1P0050001906
SCREW, THROTTLE ADJUST1P0050001007
O-RING1P0050002808
NOT AVAILABLE SEPARATELYBODY, CARBURETOR1------------------9
PLUG1P00500127010
NEEDLE - HIGH SPEED1P00500126011
PURGE BASE ASY1P00500093012
SCREW, PURGE BASE ASY1P00500027013
BULB, PURGE11253810866014
RETAINER, PURGE BULB1P00500025015
SCREW, PURGE BULB RETAINER41253106183016
COVER, DIAPHRAGM11253425213017
SCREW, DIAPHRAGM COVER21253445213018
SCREW, METERING LEVER PIN11253394203019
INCLUDES ITEMS 21-30REPAIR KIT1P00500095020
ROLLER, GUIDE1P00500100021
PIN, METERING LEVER1------------------22
VALVE, INLET NEEDLE1------------------23
LEVER, METERING1------------------24
SPRING, METERING LEVER1------------------25
STRAINER1------------------26
DIAPHRAGM, PUMP1------------------27
GASKET, PUMP1------------------28
GASKET, METERING1------------------29
DIAPHRAGM, METERING1------------------30
INCLUDES ITEMS 32-35DIAPHRAGM/GASKET KIT1P00500055031
DIAPHRAGM, PUMP1------------------32
GASKET, PUMP1------------------33
GASKET, METERING1------------------34
DIAPHRAGM, METERING1------------------35
99922204021 - 17 - REVISED 05/19/09
Table of Contents Part Number Index
SRM-230 Trimmer Carburetor -- RB-K70A

Echo TRIMMER SRM-230 Specifications

General

Shaft Type	Straight
Engine Type	2-Stroke
Handle Type	Loop Handle
Cutting Swath	17 in
Starting System	Recoil
Fuel Tank Capacity	0.55 liters
Cutting Width	17 in
Fuel Capacity	0.55 liters
Power Output	0.7 kW
