Echo WT190

WHEELED TRIMMER
5
7/10
Push
WT190 HANDLEBAR ASSY.
ASSEMBLY, WT190 HANDLEBAR
ITEM PART NUMBER DESCRIPTION
1 12324 CABLE, BRAKE CONTROL
2 12326 PAD, FOAM HANDLEBAR
3 15030 WASHER, 1/4 FLAT ZP
4 15176 SCREW, 11/32 X 7/8 HWH AB THREAD ZP
5 15219 BOLT, 5/16 X 1 HHCS GR5 NC ZP
6 15250 WASHER, 5/16 FLAT ZP
7 15342 BOLT, 1/4 X 1-1/2 HHCS GR5 ZP
8 15355 NUT, 1/4 NE NYLOCK ZP
9 15356 NUT, 5/16 NE NYLOCK ZP
10 15403 BOLT, 5/16-18 X 1-3/4 HCS GR5 ZP
11 15754-00 BOLT, 5/16 X 2-1/4 HCPS GR5
12 17320 STRAP, 11 IN. BLACK TIE
13 18008-00 CONTAINER, MANUAL
14 18955-00 CAP, PLASTIC 3/4 X 1-1/2 TUBE
15 72732-12 BAIL, TRIMMER
16 72760 HANDLEBAR, TRIMMER
17 73630-35 BODY, TRIMMER
18 74964-12 TUBE, CONTAINER MANUAL
19 75504-12 BOTTOM, TRIMMER FRAME
20 75518-12 CHANNEL, HANDLE SUPPORT
