Installation Guide
6
tel - 1-866-766-2267
email - gmsupport@echomaster.com
Illustrations are typical and may not match exact vehicle detail
Step 4
Starting at the front side of the door trim, use a plastic panel
removal tool to pry towards you to release the 3 clips attaching
it to the door. Once the 3 clips have been released, slide the
panel forward and set aside.
Door Disassembly (continued)
FCTP-GM2003
Trailering Camera System
Step 6
Starting at the top inside edge of the door panel, pull the
panel towards you, to release the fasteners, working your
way down and towards the rear of the door and then back
up and towards the door lock post.
Step 5
Remove the 2 x 7mm bolts located behind the door trim
panel.
It is normal for the silver clips to remain in the door.
Using a small flat blade pry tool you should be able
to remove them from the door and place them back
onto the door trim.
NOTE
