117

◆ Interface：3PIN

◆ Output signal：analog signal

◆ Weight：2.3g

(3)Components Needed:

Keyestudio UNO*1

keyestudio

Photoresistor

Module*1

keyestudio Yellow LED

Module*1

15cm 3pin F-F

26AWG DuPont

Line*2

USB Cable*1

(4)Connection Diagram:

Please note that the pins G,V and S on the push button module should

be connected with G, V and A0 on the expansion board respectively

while the pins G,V and S on the LED module should be linked with G,V

and 3 respectively.
