Vin
You can supply an external voltage input DC7-12V through this
pin to the board.
Analog Pins
The board has 6 analog inputs, labeled A0 through A5.
Can also used as digital pins, A0=D14, A1=D15, A2=D16, A3=D17,
A4=D18, A5=D19.
For analog port, you can connect through female headers, or
through pin headers (labeled S) of 2.54mm pitch.
IIC Communication Pin
Connect to the IIC communication.
4Pins (GND, VCC (3.3V or 5V controlled by slide switch), SDA, SCL)
RESET Button
You can reset your board to start the program from the initial
status.
(2) Install Driver
Windows 10:
The driver will be automatically installed if you plug control board to your
computer. Then the COM port is shown below:
