(3)Components Needed:

Keyestudio UNO*1

keyestudio Push

Button Module*1

keyestudio Yellow

LED Module*1

20cm 3pin F-F

26AWG DuPont

Line*2

USB Cable*1

(4)Connection Diagram

Please note that the pins G,V and S on the push button module should

be connected with G, V and D2 on the development board respectively

while the pins G,V and S on the LED module should be linked with G,V

and D3 on the development board respectively.
